Performance Benchmarking of Video Codecs: A Beginner's Guide

More than 33 exabytes of data cross the internet every day, and streaming video makes up around 54% of everything flowing downstream, according to Sandvine's 2024 Global Internet Phenomena Report. Almost every one of those videos passed through a codec before it reached a screen. Codecs are what make that possible. An hour of uncompressed 1080p video is about 336 gigabytes. The same hour streams to a phone in around two gigabytes. Nothing else in a video product does that much work, and the codec doing it decides how much a company pays for bandwidth, how good the picture looks, how warm a phone gets, and whether playback works at all on a five-year-old Android device.

So "which codec should we use?" deserves an answer based on evidence rather than instinct. Codec vendors publish impressive numbers, and those are usually true, for their test content and on their hardware. Whether they hold for a different kind of video is a separate question, and answering it is what codec benchmarking means.

In this blog post we will look at what a codec actually does, the three consequences that make codec choice a business decision as well as a technical one, how video quality gets measured when "it looks fine to me" is not good enough, and the five principles that separate a benchmark you can trust from one that quietly misleads you.

Every video users watch has been squeezed by an encoder first. How well that squeeze works is what codec benchmarking measures.

What is a video codec?

A codec is really two programs working as a pair. The encoder squeezes video down to a smaller size, the decoder unpacks it again for playback. Put the halves together and you get the name: co-dec. The four you will meet most often are H.264 (also called AVC), H.265 (also called HEVC), VP9 and AV1.

Here is a distinction that trips up a lot of people at first. A codec is a specification, a written standard. The thing you actually run is an implementation of it, and there are usually several. H.264 is one standard - x264 is the popular software encoder for it. AV1 is another standard, SVT-AV1 is one encoder for it. Your phone and GPU have hardware encoders built in too.

Why video has to be compressed at all

Uncompressed video is absurdly large. A single 1080p frame holds about two million pixels, which works out to roughly 3 MB of raw data. At 30 frames per second that is 93 MB every second, or about 746 megabits per second flowing continuously, roughly 336 gigabytes for a single hour. No home internet connection can carry that. A typical 1080p stream arrives at around 5 megabits per second instead. The codec's job is to bridge those two numbers - throwing away roughly 149 parts in 150 while keeping the video looking essentially unchanged.

It manages this mostly by noticing repetition. Most of any frame looks a lot like the frame before, so instead of storing every frame in full, the encoder stores the differences. It also discards detail that human eyes are bad at noticing, such as fine gradations of colour. Better codecs are simply better at finding that redundancy and better at judging what nobody will miss.

The codecs you will hear about

Four names dominate, and they arrived in roughly this order:

If you want to see how these codecs compare, we suggest you read: Video Quality Comparison for Various Codecs at Different Resolutions and Bitrates (Part 3)

Why codec performance matters

Three separate consequences, each landing on someone different.

It sets the bandwidth bill

Content delivery networks,  the services that store copies of your video around the world and serve it to nearby viewers, charge for data leaving their servers. Reduce the data needed per video and that bill falls almost proportionally.

The savings are large enough to matter. In a comparison run by the Streaming Learning Center, the same football clip was encoded with each codec and tuned so that all four looked equally good to a quality model. H.264 needed 9.0 MB, HEVC 7.1 MB, VP9 6.8 MB, and AV1 just 4.1 MB. Same apparent quality, 54% less data.

But better compression is not free. Squeezing harder takes more computing power, and the same study estimated AV1 encoding at roughly four times the cost of H.264. That produces a genuine break-even calculation. Namely, a video has to be watched somewhere between 950 and 4,000 hours in total before the delivery savings repay the extra encoding. Popular content clears that bar easily, but a large library of rarely-watched videos may never clear it at all.

It drains batteries and heats phones

Unpacking video takes work too, and this is where users feel codec choice directly.

Modern phones and laptops contain dedicated hardware for decoding common codecs, which is fast and uses very little power. If a device does not have the right hardware for a codec, it has to do the work using the main processor instead. This is called falling back to software, and it costs far more power. The battery drains faster, the phone gets warm, and once it gets too warm the processor deliberately slows down to cool off. At that point the video starts to stutter and skip frames.

Playback cost is also the part most often missing from codec comparisons, including published ones. A codec can compress brilliantly and still be the wrong choice for a mobile app, simply because playing it back costs too much.

It decides who can watch at all

Compatibility is not something you balance. A device can either play the video, or it cannot. A survey of 1.14 million browser sessions in early 2026 found H.264 and VP9 supported almost everywhere, at 99.94% and 99.99%, while AV1 reached about 91.5% and HEVC about 85.1%. Those numbers are a rough guide. The survey records what browsers report rather than what devices can really do. The ranking is what matters, and it matches what the rest of the industry sees.

The practical result is that newer codecs are almost never deployed alone. They ship alongside an older fallback, so that whatever a viewer's device supports, something plays. That means encoding and testing several versions of every video instead of one, which is a real cost that arrives attached to the compression saving.

What "performance" actually means here

There is no single score, and expecting one is the first mistake. Codec performance pulls in three directions at once.

Compression efficiency is how little data is needed to reach a given level of visual quality. Computational cost covers the processing power, time and energy consumed at both ends - encoding and decoding. Compatibility is how much of your audience can play the result smoothly.

Newer codecs win decisively on the first, usually lose on the second, and often lose on the third. AV1 is the clearest example: unbeatable compression, expensive encoding, incomplete device support. So a benchmark that measures only compression efficiency will recommend AV1 every time, which makes it useless as a benchmark because it was never capable of producing a different answer.

The useful output is a statement like: this codec saves 40% of our bandwidth, costs four times as much to encode, and cannot reach 8% of our users without a fallback. That is something a team can actually decide on.

Compression savings show up on the bandwidth bill. The cost of achieving them shows up in compute and in the user's battery.

How video quality gets measured

"It looks fine to me" does not scale. Comparing four codecs at four quality settings means sixteen files, and human eyes are inconsistent, slow, and easily influenced by knowing which file is which. So the industry uses objective metrics. Algorithms that compare the compressed video against the original and produce a number.

Three of them do most of the work, and each has a distinct character.

PSNR compares the two videos (compressed version against the original) pixel by pixel and reports the difference in decibels. It is fast, universally available, and useful for spotting when something has changed. Its weakness is that it does not match human perception especially well. Two files can score identically and look noticeably different, particularly where blurring is involved.

SSIM looks at brightness, contrast and structural patterns rather than individual pixels, producing a score between 0 and 1. Above about 0.97, degradation is effectively invisible. It is good at catching the blocky artifacts people actually complain about.

VMAF was developed by Netflix and has become the default for streaming work. It combines several different measurements using a model trained on scores from real human viewers, and reports a result on a scale from 0 to 100. Of the three, it comes closest to predicting what a person would say.

Two habits make these metrics trustworthy. First, use at least two of them, because when they disagree sharply, that gap is telling you something, usually that fine detail or grain has been lost, and it is worth opening the frames to see what. Second, remember what these scores actually are: software predicting what a person would probably say, and they are usually right. When one surprises you, go and look at the video rather than trusting the number.

We explore how these three metrics behave, including cases where they contradict each other, in our article Full-Reference Quality Metrics: VMAF, PSNR and SSIM. For how content type changes the picture, Temporal and Spatial Features for Video Quality Assessment is a useful companion.

Five principles of a fair benchmark

The tools matter far less than the method. These five principles make the difference between results you can use and results that only look right.

Compare at equal quality, not equal settings

Every encoder has a quality dial, and the numbers on those dials mean completely different things between codecs. Setting all four codecs to "23" and comparing the resulting file sizes feels like a fair test but in reality it is not. It’s like comparing a size 8 shoe in the UK against a size 8 in the US.

A fair comparison tunes each codec until all the outputs reach the same measured quality, then compares what each one needed to get there. The industry has a standard measure for exactly this, called BD-Rate, which reports the average data saving between two codecs at matched quality.

Test content that resembles yours

Compression performance depends heavily on what is in the video. A football match, with constant motion and grass texture, is a completely different problem from a person talking to a webcam against a plain wall. Gains measured on one do not transfer to the other.

Test two or three short clips that reflect what your product genuinely carries. This single choice affects results more than most people expect, and it is the usual reason a benchmark you read about gives different numbers when you run it yourself.

Test a range, not a single point

One measurement tells you almost nothing, because the relationship between data and quality is a curve rather than a line. Quality climbs steeply at low bitrates, then flattens out.

Finding where it flattens is often the most valuable result of the whole exercise. In our own testing across resolutions and bitrates, every codec was already close to its best possible quality by around 2,500 kbps, and spending more bought almost nothing anyone could see. H.265 reached its best 1080p scores at just 500 kbps. That flattening point marks exactly where a product starts paying for data nobody perceives, and testing at a single setting will never reveal it.

AV1 needs less than half the data H.264 does for the same measured quality, but takes around four times as much computing power to produce it.

Change one thing at a time

Encoders have dozens of settings, and several of them shift results as much as the codec itself does. The most dramatic is the effort setting, which controls how hard the encoder searches for savings. In one published test, moving between the slowest and fastest effort levels changed encoding speed by a factor of 124 while barely moving the quality score.

If two things change between runs, the result tells you nothing about either. Fix every setting, record what you fixed, and change one variable per comparison.

Verify the measurement itself

This is the principle beginners skip, and it can invalidate everything.

Quality metrics work by comparing the first frame of one file against the first frame of the other, then the second against the second, and so on. If the two files are misaligned by even a single frame, the comparison is between the wrong pairs, and the resulting score looks perfectly normal. A misalignment of even one frame can shift a PSNR score by several decibels, easily enough to reverse a conclusion.

Where it gets harder

Everything we mentioned above can be done on one machine, and it answers a useful question: which codec compresses our kind of content most efficiently.

What it cannot tell you is what users will actually experience. That depends on real decoders on real devices, real network conditions, and real batteries - and none of those exist on a test machine. Getting to that stage means moving from a laptop to device labs and controlled networks. We cover that pipeline in How We Automate Audio and Video Quality Testing, and How to Produce Research-Grade Benchmarking Data on Conferencing Platform Performance shows the scale a genuinely defensible comparison reaches: 360 tests producing 2,304 video files across 14 devices, three internet providers and three bandwidth conditions.

The principles do not change, there is simply far more of it, and it has to be automated.

Conclusion

A codec is the reason an hour of video takes two gigabytes instead of 336. Because it does that much work, the choice of codec decides three things simultaneously: what a business pays to deliver video, how much battery and heat playback costs its users, and how many of them can watch at all.

Those consequences are why the decision deserves measurement rather than a vendor's claim. And measuring it well is mostly a matter of discipline rather than expertise. Compare at equal quality instead of equal settings, test content that resembles your own, measure across a range so you can see where quality stops improving, change one variable at a time, and confirm your measurement is comparing what you believe it is.

Follow those and the numbers will point somewhere worth going. Skip them and you will still get numbers, equally confident, and pointing at the wrong answer.
